WILWOOD 07-18 WRANGLER JK FULL DISC BRAKE KIT

Complete Kit Includes:

• Superlite 6 Piston Bolt-on Front Hat & 12.88" Disc Brake Kit (Part #140-13880) for Both Front Wheels
• Superlite 4 Piston Bolt-on Rear Hat & 12.88" Disc Brake Kit (Part #140-13969) for Both Rear Wheels

The unsurpassed braking capacity of the Forged Narrow Superlite calipers serves as the base of this 12.88” big rotor kit for these popular 2007-up Jeep JK or Wrangler model vehicles. Forged Narrow Superlite kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used. Big brake kits provide increased brake capacity and complementary style with wheel, tire, and suspension upgrades. Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application.

Each kit is engineered specific for each vehicle.

These Big Brake kits require at least 17" diameter wheels.

Front Kit Includes Parts for Both Front Wheels:

• 1.25" Thick X 12.88" O.D. Rotors
• Forged Narrow Superlite 6R Calipers - Black or Red
• BP-10 Smart Compound Brake Pads

Rear Kit Includes Parts for Both Rear Wheels:

• 0.81" Thick X 12.88" O.D. Rotors
• Narrow Superlite 4R Calipers - Black or Red
• BP-10 Smart Compound Brake Pads
• Brake Hats &

Complete kit weighs approximately 107 lbs.

You can view and download the complete assembly instruction booklet for the Front Kit and the Rear Kit.

Complete Kit Includes:

• Superlite 6 Piston Bolt-on Front Hat & 14.00" Disc Brake Kit (Part #140-12440) for Both Front Wheels
• Superlite 4 Piston Bolt-on Rear Hat & 14.00" Disc Brake Kit (Part #140-14066) for Both Rear Wheels

The unsurpassed braking capacity of the Forged Narow Superlite 6R four-piston caliper serves as the base of this 14” big rotor kit for these popular 2007-up Jeep JK or Wrangler model vehicles. FNSL6 kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used. Big brake kits provide increased brake capacity and complementary style with wheel, tire, and suspension upgrades. Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application.

Forged Narrow Superlite 4R four piston calipers are combined with BP-20 compound pads and 14” rotors in this group of big brake kits for custom high performance street and show machines. This group of specialized kits for cars, trucks, and SUVs retain full use of the OE parking brake, master cylinder output, and ABS where used. FNSL4R rear kits provide complementary style and performance with 13” and larger front brake upgrades in conjunction with wheel, tire, and suspension upgrades. Optional caliper finishes and rotor designs enable the builder to match style and performance on all applications.

These Big Brake kits require at least 18" diameter wheels.

Front Kit Includes Parts for Both Front Wheels:

• 1.25" Thick X 14.00" O.D. Rotors
• Forged Narrow Superlite 6R Calipers - Black or Red
• BP-20 Smart Compound Brake Pads

Rear Kit Includes Parts for Both Rear Wheels:

• 0.81" Thick X 14.00" O.D. Rotors
• Forged Narrow Superlite 4R Calipers - Black or Red
• BP-20 Smart Compound Brake Pads
• Brake Hats

Complete kit weighs approximately 126 lbs.

You can view and download the complete assembly instruction booklet for the Front Kit and the Rear Kit.
