SPRINT KIT,DP,QUICK CHANGE IN,.810 X 10.50" TI DIS
SPRINT KIT,DP,QUICK CHANGE IN,.810 X 10.50" TI DIS
SKU:WIL 140-9751
Regular price
$1,149.99
Regular price
Sale price
$1,149.99
Unit price
per
Couldn't load pickup availability
DYNAPRO FORGED BILLET RADIAL MOUNT CALIPER:
*COMPUTER FEA DESIGNED & FULLY CNC MACHINED BILLET FORGINGS ARE UNMATCHED FOR RIGIDITY, STRENGTH, & RESISTANCE TO BODY SEPARATION AND DEFLECTION UNDER LOAD
*FOUR 1.75" STAINLESS STEEL PISTONS GENERATE HIGH CLAMPING FORCE AND BALANCED PAD LOADING WITH HIGH RESISTANCE TO CORROSION AND SLOWER HEAT TRANSFER THAN CARBON STEEL OR ALUMINUM PISTONS
*QUICK-CLIP PAD RETAINERS GIVE QUICK AND EASY ACCESS FOR PAD INSPECTION OR SERVICE WITHOUT THE NEED FOR TOOLS OR CALIPER REMOVAL
*RADIAL MOUNTING ASSURES SECURE CALIPER ATTACHMENT WITHOUT DEFLECTION TO THE REAR AXLE SIDE BELL. TWO PLANES OF ADJUSTMENT PROVIDE PRECISE LATERAL & RADIAL ALIGNMENT OF THE CALIPER AND PADS OVER THE ROTOR
*SPRING LOADED SRS BRIDGE PLATES DAMPEN VIBRATION AND ENGAGEMENT HARMONICS WHILE REDUCING BRIDGE WEAR FROM GOUGING BY THE BRAKE PAD BACKING PLATE
*INTERNAL FLUID PASSAGES ELIMINATE ALL EXTERNAL FLUID TRANSFER TUBE PROBLEMS
*SIDE INLET FLUID PORTS SIMPLIFY THE PLUMBING AND FOUR CORNER BLEED SCREWS GUARANTEE EFFECTIVE GAS EVACUATION FROM BOTH SIDES IN ALL MOUNTING POSITIONS
POLY METALLIC TITANIUM 10.50" X .810" VENTED ROTOR:
*SPRINT RACING'S LIGHTEST .810" ROTOR WEIGHS ONLY 2.37 LBS
*THE DRILLED, SLOTTED, & SCALLOPED DESIGN WITH 24 COOLING VANES PROVIDES EXCELLENT HIGH TEMPERATURE STABILITY, RAPID HEAT DISSIPATION, AND CONSISTENT PERFORMANCE FROM THE BRAKE PADS
*A MICROSCOPIC LAYER OF HARD, HIGH-DENSITY POLYMETALLIC ELEMENTS IS BONDED INTO THE SURFACE TO ADD HIGH RESISTANCE TO WEAR & EXCEPTIONAL THERMAL CONTROL PROPERTIES TO THE TITANIUM BASE
*THE FINE MICRO-FINISH SURFACE BEDS QUICKLY WITH NEW PADS. IT PROVIDES QUICK RESPONSE, LONG SERVICE LIFE FROM THE PADS, AND CONSISTENT BRAKING AT ALL TEMPERATURES
*LOWERED ROTATING WEIGHT PROMOTES QUICK ACCELERATION, DECELERATION, AND IMPROVED HANDLING
*IN ADDITION TO DECREASING THE EFFECTS OF DRIVELINE INERTIA DURING DECELERATION, THE SMALL DIAMETER ROTOR INCREASES THE CLEARANCE BETWEEN THE FUEL CELL AND OTHER CHASSIS ELEMENTS DURING SUSPENSION TRAVEL
COMPOSITION METALLIC COMPOUND BRAKE PADS:
*COMPOSITION METALLIC COMPOUND PADS ARE SPECIALLY FORMULATED FOR USE WITH ADVANCED POLYMETALLIC COATING TECHNOLOGY
*TRACK PROVEN 7816-CM PADS PROVIDE IMMEDIATE RESPONSE, HIGH FRICTION, LONG WEAR, & FADE-FREE PERFORMANCE AT ALL TEMPERATURES
AXLE CLAMP WITH DYNAMIC MOUNT ROTOR ADAPTER:
*WEIGHING ONLY 1.07 LBS, THIS IS THE LIGHTEST WEIGHT AXLE CLAMP AND FLOATING ROTOR MOUNT KIT AVAILABLE
*THE SPLINED CLAMP MAINTAINS A FIXED POSITION ON THE AXLE AND THE SLOTTED ADAPTER PLATE ALLOWS THE ROTOR TO "FLOAT" ON T-NUTS AT THE MOUNTING POINTS
*STRESSES AND DISTORTION FROM THERMAL EXPANSION THAT CAN LEAD TO COMPONENT FATIGUE AND HARSH PEDAL FEEDBACK TO THE DRIVER ARE VIRTUALLY ELIMINATED. A SMALL MARGIN OF LATERAL FLOAT KEEPS THE ROTOR CENTERED BETWEEN THE PADS TO ASSURE A COMPLETE RELEASE AND NO DRAG DURING ACCELERATION
RADIAL MOUNT BRACKET & HARDWARE:
*MACHINED BILLET CALIPER BRACKETS GIRDLE THE MOUNTING BOSSES ON THE SIDE BELL TO PROVIDE A STURDY AND DEFLECTION FREE ATTACHMENT POINT FOR THE CALIPER
*CALIPER HEIGHT CAN BE SHIMMED FOR PRECISE ALIGNMENT BETWEEN THE OUTSIDE PAD RADIUS AND OUTSIDE DIAMETER OF THE ROTOR
*RADIAL MOUNTING SIMPLIFIES CALIPER AND ROTOR SERVICE BY ELIMINATING THE NEED TO REMOVE THE BRACKET OR MOUNTING BOLTS FROM THE SIDE BELL
*HIGH STRENGTH STEEL STUDS, LOCK NUTS, MOUNT BOLTS, WASHERS, AND ALIGNMENT SHIMS ARE INCLUDED TO COMPLETE AN ACCURATE & SECURE INSTALLATION
