INTAKE MANIFOLD,BBF 429/460,HI-RAM

BRAND NEW WEIAND HI-RAM INTAKE MANIFOLD, 2800-9000 RPM,429-460, FITS FORD BIG BLOCK V8

THESE TUNNEL RAM MANIFOLDS ARE USED PRIMARILY IN DRAG RACING, TRACTOR/TRUCK PULLS AND PERFORMANCE MARINE APPLICATIONS WHERE HIGH RPM PERFORMANCE IS REQUIRED. THE EFFECTIVE RPM RANGE IS BETWEEN 3,200 TO 9,000 RPM. THE WEIAND HI-RAM, WITH THE PATENTED D-SHAPED PORT RUNNERS AND LARGE PLENUM CHAMBER, PROVIDE OPTIMUM VELOCITY OF THE AIR/FUEL MIXTURE TO THE CYLINDER HEAD INTAKE PORTS. FOR MAXIMUM PERFORMANCE IN A NATURALLY ASPIRATED COMPETITION APPLICATION, THE WEIAND HI-RAM IS THE MANIFOLD OF CHOICE!

NOTE: PORT-MATCH THE MANIFOLD TO THE CYLINDER HEADS FOR BEST PERFORMANCE RESULTS (COBRA JET AND SUPER COBRA JET HEADS WILL REQUIRE SIGNIFICANT PORT MATCHING SINCE THEY HAVE LARGER THAN STOCK PORTS).

FITS:

• FORD BIG BLOCK V8

FEATURES:

• 2 X 4 CARBURETOR TOP
• SQUARE FLANGE CARBURETOR MOUNTING
• SPECIAL D-SHAPED PORT RUNNER DESIGN
• POWER BAND: 2800-9000 RPM
• LARGE VOLUME PLENUM
• HEIGHT: FRONT 9.93", REAR 10.31"
• PORT SIZE: 2.05" HEIGHT 1.83" WIDTH
• CARB FLANGE CENTER-TO CENTER 9.875"
• WEIAND NOSTALGIA SERIES INTAKE MANIFOLD

SPECS:

• BRAND: WEIAND
• CONSTRUCTION: CAST
• EMISSION CODE: 4
• ENGINE: FORD BIG BLOCK V8
• FINISH: SATIN
• FRONT HEIGHT: 9.93"
• FUEL SYSTEM TYPE: CARB
• MANIFOLD TYPE: HI-RAM
• PRODUCT TYPE: INTAKE MANIFOLD
• REAR HEIGHT: 10.31"
• RPM POWER BAND: 3200-9000
