CARBURETOR,4150,DRAG RACE,ALUM,850CFM,MS,AN
CARBURETOR,4150,DRAG RACE,ALUM,850CFM,MS,AN
SKU:QFT Q-850-AN
Brand New Holley Quick Fuel Q-Series Carburetor, Red Billet & Shiny Finish, 850 CFM, Drag Racing, Annular Booster, 4150 Model (Part #Q-850-AN).
Q-Series carburetors are purpose-built for the dragstrip. Equipped with notched floats & secondary jet extensions. High-flow aluminum main body is lightweight & features recessed air bleed cavities for improved air flow. Die-cast venturi are machined to exacting tolerances for outstanding throttle response. Billet metering blocks ensure a uniform fuel curve, while throttle-bodies enhance durability. QFT QuickLink system makes adjusting the secondaries easy on models equipped with mechanical secondaries.
NOTE: This carburetor has the square bore flange bolt pattern. It replaces Holley, Edelbrock, Carter AFB & Autolite style carburetors with 5 3/16" x 5 5/8" bolt pattern. If you have a spreadbore style intake manifold, an adapter is needed to install this carburetor, similar to Mr. Gasket #1932.
Features:
- Lightweight aluminum main body
- Aluminum fuel bowls with dual sight glass windows
- Billet metering blocks with 4-corner idle system
- Changeable idle feed & power valve channel restrictions
- Billet aluminum throttle body provides exceptional precision & strength
- PTFE coated & sealed shafts
Specs:
- Barrels: 4
- Billet Color: Red
- Booster: Annular
- Brand: Quick Fuel
- Carburetor Use: Performance & Race
- CFM: 850
- Choke: None
- Circuit: 2
- Finish: Shiny
- Fuel: Gasoline
- Fuel System: Carbureted
- High Speed Air Bleed: 33
- Idle Air Bleed Size: 73
- Marine Use: No
- Material: Aluminum
- Model: Q-Series
- Primary Main Jet: 76
- Primary Power Valve: 45
- Primary Pump Nozzle Size: 32
- Product Type: Carburetor
- Secondaries: Mechanical
- Secondary Main Jet: 84
- Supercharged Application: No
- Throttle Bore: 1-3/4"
You can view and download the complete assembly instruction booklet here.
