ALTERNATOR,12SI,100 AMP,W/BAFFLE,CONE,CHROME

ALTERNATOR,12SI,100 AMP,W/BAFFLE,CONE,CHROME

PMM 17294-332

$229.99
$229.99
View full details

Brand New Chrome Powermaster 12SI Style Alternator with Cone and Baffle Plate, 100 Amp (Part #17294-332).

Features:

  • These Powermaster alternators give you the ultimate custom billet look at an affordable price
  • Features a smooth die cast housing with teardrop design
  • Smooth back with special Powermaster vents for pull through cooling
  • Gold battery post
  • The "SI" in the model number stands for Systems Integrated, meaning the voltage regulator is inside of the alternator
  • Can be used as a one wire or a three wire
  • As you can see from the picture of the back at the bottom, this alternator has the two wire plug-in connector at the 3:00 o'clock assembly position
  • Includes a V-belt pulley & High volume fan
  • Powermaster includes a proof of performance tag with each alternator
  • Increased amps will allow additional accessories to be used if necessary
  • Specifications:
    • 70 Amps at 2,400 RPM
    • 100 Amps Maximum
    • 13.2 VDC at 77 degrees Fahrenheit
    • Operating Range: -40C to 150C
    • Maximum RPM: 18,000

Fits:

  • Chevy:
    • 1967-1971 Camaro, All (Stock alternator was 61 Amp)
    • 1972-1980 Camaro, All (Stock alternator was 63 Amp)
    • 1981-1982 Camaro, All (Stock alternator was 94 Amp)
    • 1983-1984 Camaro, All except 5.0L (305S) (Stock alternator was 94 Amp)
    • 1985-1986 Camaro, 2.8L (173) (Stock alternator was 94 Amp)
    • 1985-1986 Camaro, 5.0L (305G,H) (Stock alternator was 94 Amp)
    • 1963-1968 Corvette, All (Stock alternator was 61 Amp)
    • 1969-1979 Corvette, All (Stock alternator was 63 Amp)
    • 1980-1982 Corvette, All (Stock alternator was 63 Amp)
    • 1982-1986 Cavalier, 2.0L & 2.8L (Stock alternator was 94 Amp)
    • 1972-1979 Chevelle, All (Stock alternator was 63 Amp)
    • 1972-1979 SS Chevelle, All (Stock alternator was 63 Amp)
    • 1963-1971 El Camino, All (Stock alternator was 61 Amp)
    • 1972-1979 El Camino, All (Stock alternator was 63 Amp)
    • 1980-1982 El Camino, All (Stock alternator was 63 Amp)
    • 1983-1985 El Camino, All (Stock alternator was 94 Amp)
    • 1986-1988 El Camino, All (Stock alternator was 94 Amp)
    • 1963-1972 Impala, All (Stock alternator was 61 Amp)
    • 1973-1979 Impala, All (Stock alternator was 63 Amp)
    • 1970-1972 Monte Carlo, All (Stock alternator was 61 Amp)
    • 1973-1979 Monte Carlo, All (Stock alternator was 63 Amp)
    • 1980-1982 Monte Carlo, All (Stock alternator was 63 Amp)
    • 1983-1984 Monte Carlo, All (Stock alternator was 94 Amp)
    • 1985-1988 Monte Carlo, All (Stock alternator was 94 Amp)
    • 1972-1979 Nova, All (Stock alternator was 63 Amp)
    • 1985 Astro Van, All (Stock alternator was 94 Amp)
    • 1969-1971 Blazer, All (Stock alternator was 61 Amp)
    • 1972-1982 Blazer, All except HD (Stock alternator was 63 Amp)
    • 1983-1986 Blazer, All except HD (Stock alternator was 94 Amp)
    • 1987-1988 Blazer, 5.0L, 5.7L (Stock alternator was 94 Amp)
    • 1987-1988 Blazer, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1989-1994 Blazer, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1985 Safari Van, All (Stock alternator was 94 Amp)
    • 1963-1971 Silverado C,K Series, All (Stock alternator was 61 Amp)
    • 1972-1982 Silverado C,K Series, All except HD (Stock alternator was 63 Amp)
    • 1983-1986 Silverado C,K Series, All except HD (Stock alternator was 94 Amp)
    • 1987 Silverado C,K Series, 5.0L, 5.7L (Stock alternator was 94 Amp)
    • 1987 Silverado C,K Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1963-1971 Suburban C,K Series, All (Stock alternator was 61 Amp)
    • 1972-1982 Suburban C,K Series, All except HD (Stock alternator was 63 Amp)
    • 1983-1986 Suburban C,K Series, All except HD (Stock alternator was 94 Amp)
    • 1987 Suburban C,K Series, 5.0L, 5.7L (Stock alternator was 94 Amp)
    • 1987 Suburban C,K Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1963-1971 Chevy Full Size Van G Series, All (Stock alternator was 61 Amp)
    • 1972-1980 Chevy Full Size Van G Series, All except HD (Stock alternator was 63 Amp)
    • 1981-1984 Chevy Full Size Van G Series, All except HD (Stock alternator was 94 Amp)
    • 1985-1986 Chevy Full Size Van G Series, All except HD (Stock alternator was 94 Amp)
    • 1987-1990 Chevy Full Size Van G Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1987-1989 Chevy R,V Old Style Body, All (Stock alternator was 94 Amp)
    • 1990 Chevy R,V Old Style Body, 6.2L & 7.4L RV3 (Stock alternator was 94 Amp)
    • 1982-1985 Chevy S,T Series Mini Pickup, All (Stock alternator was 94 Amp)
  • Buick:
    • 1963-1972 Centurion, Electra, Estate Wagon, Invicta, Lesabre, Wildcat, All (Stock alternator was 61 Amp)
    • 1973-1979 Centurion, Electra, Estate Wagon, Invicta, Lesabre, Wildcat, All (Stock alternator was 63 Amp)
    • 1973-1976 Century, Luxus, Regal, All (Stock alternator was 63 Amp)
    • 1977 Century, Luxus, Regal, All except 305H,J,K,L (Stock alternator was 63 Amp)
    • 1978-1982 Century, Luxus, Regal, All (Stock alternator was 63 Amp)
    • 1983-1985 Century, Luxus, Regal, All (Stock alternator was 94 Amp)
    • 1986-1987 Century, Luxus, Regal, 3.8L (231) without A/C (Stock alternator was 94 Amp)
    • 1986-1987 Century, Luxus, Regal, 5.0L (307) (Stock alternator was 94 Amp)
    • 1984-1985 Grand National, 3.8L Turbo (Stock alternator was 94 Amp)
    • 1968-1971 Gran Sport, All (Stock alternator was 61 Amp)
    • 1972 Gran Sport, 350 & 455 (Stock alternator was 63 Amp)
  • Cadillac:
    • 1963-1972 All with External Regulator (Stock alternator was 61 Amp)
    • 1973-1979 All with Internal Regulator (Stock alternator was 63 Amp)
  • GMC:
    • 1963-1971 Caballero, All (Stock alternator was 61 Amp)
    • 1972-1979 Caballero, All (Stock alternator was 63 Amp)
    • 1980-1982 Caballero, All (Stock alternator was 63 Amp)
    • 1983-1985 Caballero, All (Stock alternator was 94 Amp)
    • 1986-1988 Caballero, All (Stock alternator was 94 Amp)
    • 1963-1971 GMC Truck C,K Series, All (Stock alternator was 61 Amp)
    • 1972-1982 GMC Truck C,K Series, All except HD (Stock alternator was 63 Amp)
    • 1983-1986 GMC Truck C,K Series, All except HD (Stock alternator was 94 Amp)
    • 1987 GMC Truck C,K Series, 5.0L, 5.7L (Stock alternator was 94 Amp)
    • 1987 GMC Truck C,K Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1963-1971 Suburban C,K Series, All (Stock alternator was 61 Amp)
    • 1972-1982 Suburban C,K Series, All except HD (Stock alternator was 63 Amp)
    • 1983-1986 Suburban C,K Series, All except HD (Stock alternator was 94 Amp)
    • 1987 Suburban C,K Series, 5.0L, 5.7L (Stock alternator was 94 Amp)
    • 1987 Suburban C,K Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1963-1971 GMC Full Size Van G Series, All (Stock alternator was 61 Amp)
    • 1972-1980 GMC Full Size Van G Series, All except HD (Stock alternator was 63 Amp)
    • 1981-1984 GMC Full Size Van G Series, All except HD (Stock alternator was 94 Amp)
    • 1985-1986 GMC Full Size Van G Series, All except HD (Stock alternator was 94 Amp)
    • 1987-1990 GMC Full Size Van G Series, 6.2L Diesel (Stock alternator was 94 Amp)
    • 1987-1989 GMC R,V Old Style Body, All (Stock alternator was 94 Amp)
    • 1990 GMC R,V Old Style Body, 6.2L & 7.4L RV3 (Stock alternator was 94 Amp)
    • 1982-1985 GMC S,T Series Mini Pickup, All (Stock alternator was 94 Amp)
    • 1985 Safari, 4.3L (Stock alternator was 94 Amp)
  • Jeep:
    • 1975-1977 CJ, All V6 (Stock alternator was 63 Amp)
    • 1978-1980 CJ, All (Stock alternator was 63 Amp)
    • 1981-1982 CJ, All except 4.2L HD (Stock alternator was 94 Amp)
    • 1983-1986 CJ, All (Stock alternator was 94 Amp)
    • 1987-1990 Wrangler, All (Stock alternator was 94 Amp)
    • 1975-1977 Cherokee Limited, Commanche, Wagoneer Limited (XJ Series), All V6 (Stock alternator was 63 Amp)
    • 1978-1980 Cherokee Limited, Commanche, Wagoneer Limited (XJ Series), All (Stock alternator was 63 Amp)
    • 1981-1983 Cherokee Limited, Commanche, Wagoneer Limited (XJ Series), All except HD (Stock alternator was 63 Amp)
    • 1984-1986 Cherokee Limited, Commanche, Wagoneer Limited (XJ Series), 2.5L, 2.8L (Stock alternator was 94 Amp)
    • 1975-1977 Grand Wagoneer (J Series) Full Size, J Series Pickup, All V6 (Stock alternator was 63 Amp)
    • 1978-1979 Grand Wagoneer (J Series) Full Size, J Series Pickup, All (Stock alternator was 63 Amp)
    • 1980-1991 Grand Wagoneer (J Series) Full Size, J Series Pickup, All (Stock alternator was 94 Amp)
  • Oldsmobile:
    • 1963-1971 Cutlass & Cutlass Supreme, All (Stock alternator was 61 Amp)
    • 1972-1982 Cutlass & Cutlass Supreme, All (Stock alternator was 63 Amp)
    • 1983-1987 Cutlass & Cutlass Supreme, All (Stock alternator was 94 Amp)
    • 1988-1993 Cutlass & Cutlass Supreme, 5.0L (307) (Stock alternator was 94 Amp)
    • 1985 Cutlass Calais, All (Stock alternator was 94 Amp)
    • 1982 Cutlass Ciera, All except 3.0L (Stock alternator was 63 Amp)
    • 1983-1985 Cutlass Ciera, All (Stock alternator was 94 Amp)
    • 1985 Cutlass Ciera, 2.5L & 2.8L (Stock alternator was 94 Amp)
    • 1963-1971 F85, Vista Cruiser, 4-4-2, All (Stock alternator was 61 Amp)
    • 1972-1982 F85, Vista Cruiser, 4-4-2, All (Stock alternator was 63 Amp)
    • 1983-1987 F85, Vista Cruiser, 4-4-2, All (Stock alternator was 94 Amp)
    • 1988-1993 F85, Vista Cruiser, 4-4-2, 5.0L (307) (Stock alternator was 94 Amp)
  • Pontiac:
    • 1962-1970 Bonneville, Catalina, Executive, Grandville, Starchief, All (Stock alternator was 61 Amp)
    • 1971-1979 Bonneville, Catalina, Executive, Grandville, Starchief, Grand Safari, All (Stock alternator was 63 Amp)
    • 1980-1982 Bonneville, Catalina, Executive, Grandville, Starchief, All (Stock alternator was 63 Amp)
    • 1983-1984 Bonneville, Catalina, Executive, Grandville, Starchief, All (Stock alternator was 94 Amp)
    • 1985-1986 Bonneville, Catalina, Executive, Grandville, Starchief, 3.8L without A/C (Stock alternator was 94 Amp)
    • 1985-1986 Bonneville, Catalina, Executive, Grandville, Starchief, 5.0L (Stock alternator was 94 Amp)
    • 1984-1986 Fiero, All (Stock alternator was 94 Amp)
    • 1987 Fiero, 2.8L (Stock alternator was 94 Amp)
    • 1967-1969 Firebird, Trans Am, All (Stock alternator was 61 Amp)
    • 1970-1982 Firebird, Trans Am, All (Stock alternator was 63 Amp)
    • 1983-1985 Firebird, Trans Am, All except 2.8L with A/C & 5.0L (305F,S) (Stock alternator was 94 Amp)
    • 1986 Firebird, Trans Am, 2.8L (Stock alternator was 94 Amp)
    • 1986 Firebird, Trans Am, 5.0L (305G,H) (Stock alternator was 94 Amp)
    • 1973-1979 Grand Am, All (Stock alternator was 63 Amp)
    • 1980-1985 Grand Am, All (Stock alternator was 94 Amp)
    • 1962-1970 Grand Prix, All (Stock alternator was 61 Amp)
    • 1971-1979 Grand Prix, All (Stock alternator was 63 Amp)
    • 1980-1982 Grand Prix, All (Stock alternator was 63 Amp)
    • 1983-1987 Grand Prix, All except HD (Stock alternator was 63 Amp)
    • 1965-1971 GTO, All (Stock alternator was 61 Amp)
    • 1976-1980 Sunbird, All (Stock alternator was 63 Amp)
    • 1985-1986 Sunbird, All (Stock alternator was 94 Amp)

You can view and download the instruction sheets for this alternator here.
