PRO-MAG GENERATOR,20 AMP,CCW,RED

BRAND NEW MSD PRO MAG 20 AMP GENERATOR, CCW ROTATION, RED, BAND CLAMP, 26 DEGREE CRANKSHAFT ROTATION

THE INCREASED OUTPUT OF THE 20 AMP PRO-MAG WAS BORN OF RACERS BEING RACERS, ALWAYS ASKING FOR MORE POWER. THIS STEMMED FROM DRAG RACERS THAT WERE USING A 12 AMP SYSTEM, BUT JUST DID NOT REQUIRE A 44 AMP SYSTEM.

SPECS:

• BRAND: PRO MAG
• COLOR: RED
• PRIMARY CURRENT: 20 AMPS
• PRODUCT TYPE: MAGNETO
• RPM RATING: THROUGH 14,000 RPM
• SECONDARY CURRENT: 300 MILLIAMPS
• SPARK DURATION: 26 DEGREE CRANKSHAFT ROTATION
• SPARK ENERGY: 240 MILLIJOULES (AT THE GAP)

YOU CAN VIEW AND DOWNLOAD THE COMPLETE ASSEMBLY INSTRUCTION BOOKLETS FOR THIS PRO MAG HERE.
