PRO-MAG GENERATOR,20 AMP,CW,RED

BRAND NEW MSD PRO MAG 20 AMP GENERATOR, CW ROTATION, RED, BAND CLAMP, 26 DEGREE CRANKSHAFT ROTATION

THE INCREASED OUTPUT OF THE 20 AMP PRO-MAG WAS BORN OF RACERS BEING RACERS; ALWAYS ASKING FOR MORE POWER. THIS STEMMED FROM DRAG RACERS THAT WERE USING A 12 AMP SYSTEM, BUT JUST DID NOT REQUIRE A 44 AMP SYSTEM.

WHEN THE PICKUP IS TRIGGERED, THE SIGNAL IS SENT TO THE ELECTRONIC POINTS BOX WHERE THE SPARK DURATION IS CONTROLLED AND DIRECTED TO THE 44 COIL. EACH COIL WINDING CONTAINS OVER A POUND OF COPPER WIRE THAT IS HAND-WOUND FOR ACCURACY. THE VOLTAGE IS IMMEDIATELY STEPPED UP AND SENT TO THE MAG CAP WHERE IT GETS ACCURATELY DISTRIBUTED TO THE CORRECT SPARK PLUGS, MAXIMIZING THE EXPLOSION OF HEAT AND ENERGY IN THE CYLINDER.

SPECS:

• BRAND: PRO MAG
• COLOR: RED
• PRIMARY CURRENT: 20 AMPS
• PRODUCT TYPE: MAGNETO
• SPARK DURATION: 26 DEGREE CRANKSHAFT ROTATION
• SPARK ENERGY: 240 MILLIJOULES (AT THE GAP)

YOU CAN VIEW AND DOWNLOAD THE COMPLETE ASSEMBLY INSTRUCTION BOOKLETS FOR THIS PRO MAG HERE.
