WIRE SET,SUPER CONDUCTOR,8 CYLINDER,90F,90F

BRAND NEW MSD SUPER CONDUCTOR 8.5MM SPARK PLUG WIRE SET, 8 CYLINDER 90 DEGREE PLUG/90 DEGREE CAP (PART #31229).

ROUTING SPARK PLUG WIRES IS AN ART FORM. IT TAKES PATIENCE AND TIME TO ROUTE YOUR WIRES AWAY FROM THE HEADERS, THROUGH SEPARATORS AND TO THE DISTRIBUTOR CAP. SOME WIRE SETS FIT PERFECT, BUT A LOT OF PEOPLE WANT TO BUILD THEIR OWN SO THEY CAN ROUTE THEM EXACTLY HOW THEY SEE FIT.

OUR UNIVERSAL SPARK PLUG WIRE SETS COME WITH THE SPARK PLUG TERMINAL AND BOOT INSTALLED WITH THE OTHER END OPEN. DISTRIBUTOR CAP BOOTS AND TERMINALS ARE INCLUDED SO YOU CAN CUT THE WIRE TO THE DESIRED LENGTH, THEN INSTALL THE TERMINAL WITH THE SUPPLIED MINI-STRIPPER-CRIMPER. ITS A LITTLE MORE WORK, BUT IN THE END IT WILL BE WORTH IT.

FEATURES:

• EXTRA LONG 8.5MM WIRE SO YOU CAN CUT TO YOUR DESIRED LENGTH
• DISTRIBUTOR CAP BOOTS AND TERMINALS INCLUDED
• INCLUDES MINI-STRIPPER-CRIMPER
• WIRE LENGTHS: 2- 56", 2- 50", 2- 42", 2-32" AND COIL WIRE 32"

SPECS:

• APPLICATION: UNIVERSAL V8
• BOOT MATERIAL: SILICONE
• BRAND: MSD
• COLOR: RED
• CORE: COPPER
• PRODUCT TYPE: SPARK PLUG WIRES
• RESISTANCE: 40-50 OHMS PER FOOT
• SPARK PLUG BOOT ANGLE: 90 DEGREE
• WIRE DIAMETER: 8.5MM
• WIRE SERIES: 8.5 SUPER CONDUCTOR

YOU CAN VIEW AND DOWNLOAD THE COMPLETE ASSEMBLY INSTRUCTION BOOKLET HERE.
