MANIFOLD, 1965-79 PONTIAC 326-455, PERFORMER RPM

MANIFOLD, 1965-79 PONTIAC 326-455, PERFORMER RPM

EDL 7156

$454.95
$454.95
View full details

Brand New Edelbrock Performer RPM Intake Manifold for Pontiac 326-455 V8 (Part #7156).

Edelbrock Part # 7156 Performer RPM Pontiac intake manifold is designed for 1965-79 street 326-455 C.I.D. Pontiac V8's (except Ram Air V and 265/301 V8's). Recommended for high-performance street, strip and marine. Has clearance for HEI distributor. Will not fit under Trans Am Shaker hood without modifications.

Installation Notes:
  • No provisions for OEM choke
  • OEM carb requires conversion to electric/manual choke
  • For 1968-71 use Edelbrock # 8015 throttle bracket
  • Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant # 1076, DO NOT USE END SEALS GASKETS.
  • Hardened washers must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.

Specs:

  • Series: Performer RPM
  • Material: Aluminum
  • Gasket Or Seal Included: No
  • Recommended Intake Gasket: Edelbrock #7280
  • Manifold Height: 1-1/4" taller than stock, A-6.88", B-8.00" measured to engine block
  • Carb Pad Height: 7.45"
  • Carb Recommendations: Edelbrock Thunder Series AVS, AVS2 or Performer Series 650-800 CFM.
  • Port Exit Dimensions: 1.10" x 2.06"
  • Vehicle Model: Pontiac
  • RPM Range: 1500-6500 RPM
  • Rear Maximum Height: 8.0 in
  • Plane Type: Dual

You can view and download the complete assembly instruction booklet here.
