CYLINDER HEAD,PERFORMER LT1 SBC COMPLETE SINGLE
CYLINDER HEAD,PERFORMER LT1 SBC COMPLETE SINGLE
SKU:EDL 61905
Couldn't load pickup availability
Brand New Edelbrock Performer LT1 Cylinder Head (54cc) for 1992-1997 Small Block Chevy LT1 Engines (Part #61905).
Edelbrock part #61905 Performer small-block Chevy LT1 (1992-97) Performer complete cylinder head delivers 24 horsepower over stock and raise the peak power level by 500 rpm. This head is designed to accept factory style self-aligning rockers. This Performer LT1 cylinder head is 50-state street legal and accept factory center bolt valve covers. It features exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo. Cylinder Head Specifications: - Exhaust port location: Stock - Spark plug fitment: 14mm x 3/4 reach, gasket seat.
Installation Notes:
- Head Bolt Kit - Edelbrock # 8550
- Head Gasket - Edelbrock # 7342
- Intake Gasket - Fel-Pro # 7243
- Exhaust Gasket - Edelbrock # 7248
- Recommended spark plugs - Champion RC12YC
Specs:
- Series: Performer
- Material: Aluminum
- Quantity: Sold Individually
- Horsepower: 300-450 HP
- Seat Angle: Exhaust 45 deg/Intake 45 deg
- Intake Valve Diameter: 1.94 in
- Intake Runner Volume: 170 cc
- Push Rod Diameter: (Suggested) 0.375 in
- Valve Angle: 23 Degrees
- Valve Spring Diameter: 1.46 in
- Valve Spring Maximum Lift: 0.600 in
- Valve Stem Diameter: 0.3125 in
