SC, R2650 DP3C CHEVY/GMC 2017-18 GEN V TRUCK & SUV 6.2L NO TUNER

Brand New Edelbrock Stage 1 Supercharger Kit Compatible with 2015-2020 GM SUV & 2014-2018 Truck Gen V 6.2L without Tuner (Part #156640).

This addition to Edelbrock's expanding line of superchargers is highlighted by significant improvements for Chevrolet/GMC/Cadillac 2015-2020 SUVs and 2014-2018 full size trucks with the GM 6.2L L86 V8 engine. This is a bolt-on performance kit that is emissions legal in all 50 states and produces 576 horsepower with 537 ft-lbs of torque at the rear wheel. This is the perfect power adder whether you plan to tow a trailer, haul heavier loads, or you just want to feel your truck/SUV come to life without sacrificing daily drivability!

The Edelbrock supercharger Kit for the 6.2L V8 fits under the stock hood with absolutely no cutting or modifications required. And if you're concerned about the effect on MPG, the increase in power comes with little to no loss in fuel economy thanks to the supercharger's integrated bypass valve that mitigates parasitic power loss during normal driving. This new kit is a true bolt-on that requires no additional modifications to the stock 6.2L engine. For those who want more power, the R2650 supercharger can support more than 1,000 horsepower at the flywheel with the right combination of parts. This Edelbrock supercharger features a self-contained lubrication system with a 100,000-mile service interval with a high-capacity Dual-Pass 3-Core (DP3C) integrated intercooler and comes finished in a durable black powder-coating that blends nicely with the engine.

Compatible with:

• Cadillac:
  • 2015-2020 Escalade with L86 Engine
  • 2015-2020 Escalade ESV with L86 Engine
• Chevrolet:
  • 2014-2018 Silverado 1500 with L86 Engine

• GMC:

  • 2014-2018 Sierra 1500 with L86 Engine

  • 2015-2020 Yukon Denali with L86 Engine

  • 2015-2020 Yukon Denali XL with L86 Engine

Installation Notes:

• The 8th VIN Digit identifies the vehicle's engine. J = L86.
• The Edelbrock program will disable the Flex-Fuel E85 capability (if originally equipped).
• Fits GM SUVs & GM full size trucks with the air box on the right side
• Does not fit hybrid powertrains


Specs:

• System Type: Stage 1 - Street System

• Housing Material: Cast Aluminum
• Oil Capacity: 150 mL

• Center Housing Cooling Type: Intercooler

• Internal Step Up: Yes

• Pulley Belt Width: 6-Rib

• Outside Pulley Diameter: 3.5 in

• Maximum Torque: 537 RW ft-lb

• Maximum Horsepower: 526 RWHP

• Finish: Black Powder Coated

• Maximum Boost Pressure: 12 PSI


You can view and download the complete assembly instruction booklet here and here.
