COIL SPRING SPACER,FLAT,ADJUSTABLE,4 3/4

COIL SPRING SPACER,FLAT,ADJUSTABLE,4 3/4

051-2435

$31.99
$31.99
View full details
  • ADJUSTABLE HIDDEN WEIGHTS JACKS
  • PLATED GOLD
  • FAST ACME THREADS, WHICH HOLD THE SPACER FIRMLY IN PLACE ONCE WEIGHT IS PLACED ON THEM, YET CAN BE TURNED BY HAND WITH NO WEIGHT ON THEM
  • READY TO INSTALL
  • ALLOWS QUICK & EASY ADJUSTMENT OF RIDE HEIGHT
  • 4" OF ADJUSTMENT ALLOWING SPRING TO BE SPACED FROM 1/4" TO 4 1/4"
  • MADE TO FIT 5" & 5 1/2" O.D. SPRINGS WITH AN I.D. OF AT LEAST 3 1/4"
  • THE SPRING SEAT IS 5/8" WIDE, OR YOU CAN TURN THE ADJUSTER OVER & IT BECOMES 7/8" WIDE WITHOUT THE LIP
  • ALLOWS STOCK SHOCK TO BE USED
  • IF THE SHOCKS PASS THROUGH THE CENTER OF THE SPRINGS, THE O.D. OF THE SHOCKS CANNOT EXCEED 2 3/4"
  • SPACERS ARE DESIGNED TO WELD TO THE CHASSIS
  • THE PART THAT WELDS TO THE CHASSIS HAS A 3" I.D. & A 5" O.D.
  • THE ONLY SURE-FIRE WAY TO DETERMINE IF THESE SPACERS WILL WORK FOR YOU IS TO TAKE THE MEASUREMENTS ABOVE & SEE IF THEY WILL WORK IN YOUR APPLICATION
