BRAND NEW CURRIE JEEP TJ/XJ/LJ/MJ JOHNNY JOINT JEEPSPEED FRONT TRAC BAR (PART #CE-9120TJJ)
THE ALL NEW AND IMPROVED JOHNNY JOINT TRAC BAR FOR THE TJ/XJ/LJ/MJ FEATURES AN OFFSET JOHNNY JOINT ROD END THAT PUTS THE BAR FURTHER FORWARD PROVIDING MORE CLEARANCE BETWEEN THE DIFF AND THE TRAC BAR. OTHER FEATURES INCLUDE 1 1/4" X .250 WALL 4130 CHROME MOLY CONSTRUCTION, A WELDED IN GUSSET FROM THE BAR TO THE JOHNNY JOINT, HEAVY DUTY ADJUSTOR END WITH URETHANE BUSHING AND STEEL INSERT SLEEVE, AND SEMI-GLOSS BLACK POWDER COAT FINISH. SOME DRILLING IS REQUIRED FOR INSTALLATION. THE SUPPLIED FRAME BOLT IS A 5/8", AND THE SUPPLIED HOUSING BOLT IS 1/2". BOTH OF THESE HOLES MUST BE DRILLED TO SIZE TO ACCOMMODATE THE HEAVIER DUTY HARDWARE. A HEAVY DUTY NUT PLATE KIT IS SUPPLIED FOR THE HOUSING END. NOTE: THIS TRAC BAR IS INTENDED TO BE USED WITH A MINIMUM OF 2" OF LIFT. IT MAY WORK ON VEHICLES WITH LESS LIFT WITH DANA 30 FRONTENDS, HOWEVER, ON VEHICLES WITH NO LIFT AND A DANA 44, 9" OR 60 FRONTEND, YOU MAY RUN INTO A CLEARANCE ISSUE. ALWAYS CHECK FITMENT BEFORE DRILLING! FITS:
1997-2006 JEEP WRANGLER TJ & LJ 1986-1992 JEEP COMANCHE MJ 1984-2001 JEEP CHEROKEE XJ YOU CAN VIEW AND DOWNLOAD THE COMPLETE ASSEMBLY INSTRUCTION BOOKLET FOR THIS TRAC BAR HERE.
